Dimensions: 185*190*17mm
Weight: 0.45kg
Cells: Polycrystalline
No. of Cells: 18(2x9)
Front Cover: High Transparency Tempered
Sealing Material:EVA
Back Sheet: TPT
Frame: Aluminium alloy
Junction Box: IP65 Waterproof
Output Cables Diameter: 4MM Length:900mm
Module Type JL18-156P
Maximum Power (Pmax): 3W
Open-circuit Voltage (Voc): 10.8V
Short-circuit Current (Isc): 0.39A
Maximum Power Voltage (Vmp): 9V
Maximum Power Current (lmp): 0.35A
Maximum system voltage: 1000V
Temperature coefficients of Pmax: -0.4%/℃
Temperature coefficients of Voc: -0.38%/℃
Temperature coefficients of Isc: +0.04%/℃
